Flexible Speaker Cable
Features
- Efficient audio signal delivery using high-conductivity copper strands
- Clear sound reproduction with consistent conductor insulation thickness
- Reliable performance with minimal signal drop across long lengths
- High flexibility and low bending radius by using special PVC compound
Applications
- Loudspeaker connections in public address and audio systems
- Studio, club, and auditorium speaker wiring
- Home theater speaker installations
- General-purpose sound system cabling
Construction
- Fine conductor strands of ABC - Annealed Bare Copper
- PVC based core insulation
- Fiber for improved strength & flexibility
- Sheathing of special PVC based compound
Technical Specification
Conductor Resistance :
As per conductor resistance chart
In Accordance to :
IS:694
Core Identification :
As per colour code chart
Test Voltage :
AC 1100 V
Rated voltage:
250 V
Temperature Range :
static -15 C to +70 C
| Number / Dia of Conductor Strands (Nom.) | No. of Cores | Approx overall Dia |
|---|---|---|
| (No. / SWG) | (No.) | (mm) |
| 40/0048 | 2 | 6.5 |
| 70/0048 | 2 | 7.9 |
| 100/0048 | 2 | 7.4 |
| 100/0048 | 4 | 9.3 |
| 100/0048 | 8 | 11.8 |
| 150/0048 | 2 | 9.0 |
| 150/0048 | 4 | 10.7 |
| 200/0048 | 2 | 9.2 |
| 200/0048 | 4 | 10.8 |
| 200/0048 | 8 | 14.7 |
- The number and diameter of conductor strands are for reference only.
- The above data is only indicative and may be revised without prior intimation.
